Make custom views more accessible

If your application requires a custom view component, you must make the view more accessible. The following steps can improve your custom view's accessibility, as described on this page:

  • Handle directional controller clicks.
  • Implement accessibility API methods.
  • Send AccessibilityEvent objects specific to your custom view.
  • Populate AccessibilityEvent and AccessibilityNodeInfo for your view.

Handle directional controller clicks

On most devices, clicking a view using a directional controller sends a KeyEvent with KEYCODE_DPAD_CENTER to the view currently in focus. All standard Android views handle KEYCODE_DPAD_CENTER appropriately. When building a custom View control, make sure this event has the same effect as tapping the view on the touchscreen.

Your custom control must treat the KEYCODE_ENTER event the same as KEYCODE_DPAD_CENTER. This makes interactions with a full keyboard easier for users.

Implement accessibility API methods

Accessibility events are messages about users' interactions with your app's visual interface components. These messages are handled by accessibility services, which use the information in these events to produce supplemental feedback and prompts. The accessibility methods are part of the View and View.AccessibilityDelegate classes. The methods are as follows:

dispatchPopulateAccessibilityEvent()
The system calls this method when your custom view generates an accessibility event. The default implementation of this method calls onPopulateAccessibilityEvent() for this view and then the dispatchPopulateAccessibilityEvent() method for each child of this view.
onInitializeAccessibilityEvent()
The system calls this method to obtain additional information about the state of the view beyond text content. If your custom view provides interactive control beyond a simple TextView or Button, override this method and set the additional information about your view—such as password field type, checkbox type, or states that provide user interaction or feedback into the event—using this method. If you override this method, call its super implementation and only modify properties that are not set by the super class.
onInitializeAccessibilityNodeInfo()
This method provides accessibility services with information about the state of the view. The default View implementation has a standard set of view properties, but if your custom view provides interactive control beyond a simple TextView or Button, override this method and set the additional information about your view into the AccessibilityNodeInfo object handled by this method.
onPopulateAccessibilityEvent()
This method sets the spoken text prompt of the AccessibilityEvent for your view. It is also called if the view is a child of a view that generates an accessibility event.
onRequestSendAccessibilityEvent()
The system calls this method when a child of your view generates an AccessibilityEvent. This step lets the parent view amend the accessibility event with additional information. Implement this method only if your custom view can have child views and if the parent view can provide context information to the accessibility event that is useful to accessibility services.
sendAccessibilityEvent()
The system calls this method when a user takes action on a view. The event is classified with a user action type, such as TYPE_VIEW_CLICKED. In general, you must send an AccessibilityEvent whenever the content of your custom view changes.
sendAccessibilityEventUnchecked()
This method is used when the calling code needs to directly control the check for accessibility being enabled on the device (AccessibilityManager.isEnabled()). If you implement this method, perform the call as if accessibility is enabled, regardless of the system setting. You typically don't need to implement this method for a custom view.

To support accessibility, override and implement the preceding accessibility methods directly in your custom view class.

At minimum, implement the following accessibility methods for your custom view class:

  • dispatchPopulateAccessibilityEvent()
  • onInitializeAccessibilityEvent()
  • onInitializeAccessibilityNodeInfo()
  • onPopulateAccessibilityEvent()

For more information about implementing these methods, see the section about populating accessibility events.

Send accessibility events

Depending on the specifics of your custom view, it might need to send AccessibilityEvent objects at different times or for events not handled by the default implementation. The View class provides a default implementation for these event types:

In general, you must send an AccessibilityEvent whenever the content of your custom view changes. For example, if you are implementing a custom slider bar that lets the user select a numeric value by pressing the left or right arrow key, your custom view must emit an event of TYPE_VIEW_TEXT_CHANGED whenever the slider value changes. The following code sample demonstrates the use of the sendAccessibilityEvent() method to report this event.

Kotlin

override fun onKeyUp(keyCode: Int, event: KeyEvent): Boolean {
    return when(keyCode) {
        KeyEvent.KEYCODE_DPAD_LEFT -> {
            currentValue--
            sendAccessibilityEvent(AccessibilityEvent.TYPE_VIEW_TEXT_CHANGED)
            true
        }
        ...
    }
}

Java

@Override
public boolean onKeyUp (int keyCode, KeyEvent event) {
    if (keyCode == KeyEvent.KEYCODE_DPAD_LEFT) {
        currentValue--;
        sendAccessibilityEvent(AccessibilityEvent.TYPE_VIEW_TEXT_CHANGED);
        return true;
    }
    ...
}

Populate accessibility events

Each AccessibilityEvent has a set of required properties that describe the current state of the view. These properties include things such as the view's class name, content description, and checked state. The specific properties required for each event type are described in the AccessibilityEvent reference documentation.

The View implementation provides default values for these required properties. Many of these values, including the class name and event timestamp, are provided automatically. If you are creating a custom view component, you must provide information about the content and characteristics of the view. This information can be as simple as a button label and can include additional state information that you want to add to the event.

Use the onPopulateAccessibilityEvent() and onInitializeAccessibilityEvent() methods to populate or modify the information in an AccessibilityEvent. Use the onPopulateAccessibilityEvent() method specifically for adding or modifying the text content of the event, which is turned into audible prompts by accessibility services such as TalkBack. Use the onInitializeAccessibilityEvent() method for populating additional information about the event, such as the selection state of the view.

In addition, implement the onInitializeAccessibilityNodeInfo() method. Accessibility services use the AccessibilityNodeInfo objects populated by this method to investigate the view hierarchy that generates an accessibility event after it is received and provide appropriate feedback to users.

The following code example shows how to override these three methods in your view:

Kotlin

override fun onPopulateAccessibilityEvent(event: AccessibilityEvent?) {
    super.onPopulateAccessibilityEvent(event)
    // Call the super implementation to populate its text for the
    // event. Then, add text not present in a super class.
    // You typically only need to add the text for the custom view.
    if (text?.isNotEmpty() == true) {
        event?.text?.add(text)
    }
}

override fun onInitializeAccessibilityEvent(event: AccessibilityEvent?) {
    super.onInitializeAccessibilityEvent(event)
    // Call the super implementation to let super classes
    // set appropriate event properties. Then, add the new checked
    // property that is not supported by a super class.
    event?.isChecked = isChecked()
}

override fun onInitializeAccessibilityNodeInfo(info: AccessibilityNodeInfo?) {
    super.onInitializeAccessibilityNodeInfo(info)
    // Call the super implementation to let super classes set
    // appropriate info properties. Then, add the checkable and checked
    // properties that are not supported by a super class.
    info?.isCheckable = true
    info?.isChecked = isChecked()
    // You typically only need to add the text for the custom view.
    if (text?.isNotEmpty() == true) {
        info?.text = text
    }
}

Java

@Override
public void onPopulateAccessibilityEvent(AccessibilityEvent event) {
    super.onPopulateAccessibilityEvent(event);
    // Call the super implementation to populate its text for the
    // event. Then, add the text not present in a super class.
    // You typically only need to add the text for the custom view.
    CharSequence text = getText();
    if (!TextUtils.isEmpty(text)) {
        event.getText().add(text);
    }
}

@Override
public void onInitializeAccessibilityEvent(AccessibilityEvent event) {
    super.onInitializeAccessibilityEvent(event);
    // Call the super implementation to let super classes
    // set appropriate event properties. Then, add the new checked
    // property that is not supported by a super class.
    event.setChecked(isChecked());
}

@Override
public void onInitializeAccessibilityNodeInfo(AccessibilityNodeInfo info) {
    super.onInitializeAccessibilityNodeInfo(info);
    // Call the super implementation to let super classes set
    // appropriate info properties. Then, add the checkable and checked
    // properties that are not supported by a super class.
    info.setCheckable(true);
    info.setChecked(isChecked());
    // You typically only need to add the text for the custom view.
    CharSequence text = getText();
    if (!TextUtils.isEmpty(text)) {
        info.setText(text);
    }
}

You can implement these methods directly in your custom view class.

Provide a customized accessibility context

Accessibility services can inspect the containing view hierarchy of a user interface component that generates an accessibility event. This lets accessibility services provide richer contextual information to aid users.

There are cases where accessibility services can't get adequate information from the view hierarchy. An example of this is a custom interface control that has two or more separately clickable areas, such as a calendar control. In this case, the services can't get adequate information because the clickable subsections are not part of the view hierarchy.

Figure 1. A custom calendar view with selectable day elements.

In the example in figure 1, the entire calendar is implemented as a single view, so accessibility services don't receive enough information about the content of the view and the user's selection within the view unless the developer provides additional information. For example, if a user clicks on the day labeled 17, the accessibility framework only receives the description information for the whole calendar control. In this case, the TalkBack accessibility service announces "Calendar" or "April Calendar," and the user doesn't know what day is selected.

To provide adequate context information for accessibility services in situations like this, the framework provides a way to specify a virtual view hierarchy. A virtual view hierarchy is a way for app developers to provide a complementary view hierarchy to accessibility services that more closely matches the information on screen. This approach lets accessibility services provide more useful context information to users.

Another situation where a virtual view hierarchy might be needed is a user interface containing a set of View controls that have closely related functions, where an action on one control affects the contents of one or more elements—such as a number picker with separate up and down buttons. In this case, accessibility services can't get adequate information because an action on one control changes content in another, and the relationship of those controls might not be apparent to the service.

To handle this situation, group the related controls with a containing view and provide a virtual view hierarchy from this container to clearly represent the information and behavior provided by the controls.

To provide a virtual view hierarchy for a view, override the getAccessibilityNodeProvider() method in your custom view or view group and return an implementation of AccessibilityNodeProvider. You can implement a virtual view hierarchy by using the Support Library with the ViewCompat.getAccessibilityNodeProvider() method and provide an implementation with AccessibilityNodeProviderCompat.

To simplify the task of providing information to accessibility services and managing accessibility focus, you can instead implement ExploreByTouchHelper. It provides an AccessibilityNodeProviderCompat and can be attached as a view's AccessibilityDelegateCompat by calling setAccessibilityDelegate. For an example, see ExploreByTouchHelperActivity. ExploreByTouchHelper is also used by framework widgets such as CalendarView, through its child view SimpleMonthView.

Handle custom touch events

Custom view controls might require non-standard touch event behavior, as demonstrated in the following examples.

Define click-based actions

If your widget uses the OnClickListener or OnLongClickListener interface, the system handles the ACTION_CLICK and ACTION_LONG_CLICK actions for you. If your app uses a more customized widget that relies on the OnTouchListener interface, define custom handlers for the click-based accessibility actions. To do so, call the replaceAccessibilityAction() method for each action, as shown in the following code snippet:

Kotlin

override fun onCreate(savedInstanceState: Bundle?) {
    ...

    // Assumes that the widget is designed to select text when tapped, and selects
    // all text when tapped and held. In its strings.xml file, this app sets
    // "select" to "Select" and "select_all" to "Select all".
    ViewCompat.replaceAccessibilityAction(
        binding.textSelectWidget,
        ACTION_CLICK,
        getString(R.string.select)
    ) { view, commandArguments ->
        selectText()
    }

    ViewCompat.replaceAccessibilityAction(
        binding.textSelectWidget,
        ACTION_LONG_CLICK,
        getString(R.string.select_all)
    ) { view, commandArguments ->
        selectAllText()
    }
}

Java

@Override
protected void onCreate(Bundle savedInstanceState) {
    ...

    // Assumes that the widget is designed to select text when tapped, and select
    // all text when tapped and held. In its strings.xml file, this app sets
    // "select" to "Select" and "select_all" to "Select all".
    ViewCompat.replaceAccessibilityAction(
            binding.textSelectWidget,
            ACTION_CLICK,
            getString(R.string.select),
            (view, commandArguments) -> selectText());

    ViewCompat.replaceAccessibilityAction(
            binding.textSelectWidget,
            ACTION_LONG_CLICK,
            getString(R.string.select_all),
            (view, commandArguments) -> selectAllText());
}

Create custom click events

A custom control can use the onTouchEvent(MotionEvent) listener method to detect the ACTION_DOWN and ACTION_UP events and trigger a special click event. To maintain compatibility with accessibility services, the code that handles this custom click event must do the following:

  1. Generate an appropriate AccessibilityEvent for the interpreted click action.
  2. Enable accessibility services to perform the custom click action for users who are unable to use a touch screen.

To handle these requirements efficiently, your code must override the performClick() method, which must call the super implementation of this method and then execute whatever actions are required by the click event. When the custom click action is detected, that code must then call your performClick() method. The following code example demonstrates this pattern.

Kotlin

class CustomTouchView(context: Context) : View(context) {

    var downTouch = false

    override fun onTouchEvent(event: MotionEvent): Boolean {
        super.onTouchEvent(event)

        // Listening for the down and up touch events.
        return when (event.action) {
            MotionEvent.ACTION_DOWN -> {
                downTouch = true
                true
            }

            MotionEvent.ACTION_UP -> if (downTouch) {
                downTouch = false
                performClick() // Call this method to handle the response and
                // enable accessibility services to
                // perform this action for a user who can't
                // tap the touchscreen.
                true
            } else {
                false
            }

            else -> false  // Return false for other touch events.
        }
    }

    override fun performClick(): Boolean {
        // Calls the super implementation, which generates an AccessibilityEvent
        // and calls the onClick() listener on the view, if any.
        super.performClick()

        // Handle the action for the custom click here.

        return true
    }
}

Java

class CustomTouchView extends View {

    public CustomTouchView(Context context) {
        super(context);
    }

    boolean downTouch = false;

    @Override
    public boolean onTouchEvent(MotionEvent event) {
        super.onTouchEvent(event);

        // Listening for the down and up touch events
        switch (event.getAction()) {
            case MotionEvent.ACTION_DOWN:
                downTouch = true;
                return true;

            case MotionEvent.ACTION_UP:
                if (downTouch) {
                    downTouch = false;
                    performClick(); // Call this method to handle the response and
                                    // enable accessibility services to
                                    // perform this action for a user who can't
                                    // tap the touchscreen.
                    return true;
                }
        }
        return false; // Return false for other touch events.
    }

    @Override
    public boolean performClick() {
        // Calls the super implementation, which generates an AccessibilityEvent
        // and calls the onClick() listener on the view, if any.
        super.performClick();

        // Handle the action for the custom click here.

        return true;
    }
}

The preceding pattern helps ensure that the custom click event is compatible with accessibility services by using the performClick() method to generate an accessibility event and provide an entry point for accessibility services to act on behalf of a user performing the custom click event.
