XR_ANDROID_face_tracking OpenXR 확장 프로그램

typedef struct XrSystemFaceTrackingPropertiesANDROID {
    XrStructureType    type;
    void*              next;
    XrBool32           supportsFaceTracking;
} XrSystemFaceTrackingPropertiesANDROID;

XR_DEFINE_HANDLE(XrFaceTrackerANDROID)

XrResult xrCreateFaceTrackerANDROID(
    XrSession                                   session,
    const XrFaceTrackerCreateInfoANDROID*       createInfo,
    XrFaceTrackerANDROID*                       faceTracker);

typedef struct XrFaceTrackerCreateInfoANDROID {
    XrStructureType    type;
    void*              next;
} XrFaceTrackerCreateInfoANDROID;

XrResult xrDestroyFaceTrackerANDROID(
    XrFaceTrackerANDROID                        faceTracker);

XrResult xrGetFaceCalibrationStateANDROID(
    XrFaceTrackerANDROID                        faceTracker,
    XrBool32*                                   faceIsCalibratedOutput);

XrResult xrGetFaceStateANDROID(
    XrFaceTrackerANDROID                        faceTracker,
    const XrFaceStateGetInfoANDROID*            getInfo,
    XrFaceStateANDROID*                         faceStateOutput);

typedef struct XrFaceStateGetInfoANDROID {
    XrStructureType    type;
    void*              next;
    XrTime             time;
} XrFaceStateGetInfoANDROID;

typedef struct XrFaceStateANDROID {
    XrStructureType               type;
    void*                         next;
    uint32_t                      parametersCapacityInput;
    uint32_t                      parametersCountOutput;
    float*                        parameters;
    XrFaceTrackingStateANDROID    faceTrackingState;
    XrTime                        sampleTime;
    XrBool32                      isValid;
    uint32_t                      regionConfidencesCapacityInput;
    uint32_t                      regionConfidencesCountOutput;
    float*                        regionConfidences;
} XrFaceStateANDROID;

typedef enum XrFaceTrackingStateANDROID {
    XR_FACE_TRACKING_STATE_PAUSED_ANDROID = 0,
    XR_FACE_TRACKING_STATE_STOPPED_ANDROID = 1,
    XR_FACE_TRACKING_STATE_TRACKING_ANDROID = 2
} XrFaceTrackingStateANDROID;

typedef enum XrFaceParameterIndicesANDROID {
    XR_FACE_PARAMETER_INDICES_BROW_LOWERER_L_ANDROID = 0,
    XR_FACE_PARAMETER_INDICES_BROW_LOWERER_R_ANDROID = 1,
    XR_FACE_PARAMETER_INDICES_CHEEK_PUFF_L_ANDROID = 2,
    XR_FACE_PARAMETER_INDICES_CHEEK_PUFF_R_ANDROID = 3,
    XR_FACE_PARAMETER_INDICES_CHEEK_RAISER_L_ANDROID = 4,
    XR_FACE_PARAMETER_INDICES_CHEEK_RAISER_R_ANDROID = 5,
    XR_FACE_PARAMETER_INDICES_CHEEK_SUCK_L_ANDROID = 6,
    XR_FACE_PARAMETER_INDICES_CHEEK_SUCK_R_ANDROID = 7,
    XR_FACE_PARAMETER_INDICES_CHIN_RAISER_B_ANDROID = 8,
    XR_FACE_PARAMETER_INDICES_CHIN_RAISER_T_ANDROID = 9,
    XR_FACE_PARAMETER_INDICES_DIMPLER_L_ANDROID = 10,
    XR_FACE_PARAMETER_INDICES_DIMPLER_R_ANDROID = 11,
    XR_FACE_PARAMETER_INDICES_EYES_CLOSED_L_ANDROID = 12,
    XR_FACE_PARAMETER_INDICES_EYES_CLOSED_R_ANDROID = 13,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_DOWN_L_ANDROID = 14,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_DOWN_R_ANDROID = 15,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_LEFT_L_ANDROID = 16,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_LEFT_R_ANDROID = 17,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_RIGHT_L_ANDROID = 18,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_RIGHT_R_ANDROID = 19,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_UP_L_ANDROID = 20,
    XR_FACE_PARAMETER_INDICES_EYES_LOOK_UP_R_ANDROID = 21,
    XR_FACE_PARAMETER_INDICES_INNER_BROW_RAISER_L_ANDROID = 22,
    XR_FACE_PARAMETER_INDICES_INNER_BROW_RAISER_R_ANDROID = 23,
    XR_FACE_PARAMETER_INDICES_JAW_DROP_ANDROID = 24,
    XR_FACE_PARAMETER_INDICES_JAW_SIDEWAYS_LEFT_ANDROID = 25,
    XR_FACE_PARAMETER_INDICES_JAW_SIDEWAYS_RIGHT_ANDROID = 26,
    XR_FACE_PARAMETER_INDICES_JAW_THRUST_ANDROID = 27,
    XR_FACE_PARAMETER_INDICES_LID_TIGHTENER_L_ANDROID = 28,
    XR_FACE_PARAMETER_INDICES_LID_TIGHTENER_R_ANDROID = 29,
    XR_FACE_PARAMETER_INDICES_LIP_CORNER_DEPRESSOR_L_ANDROID = 30,
    XR_FACE_PARAMETER_INDICES_LIP_CORNER_DEPRESSOR_R_ANDROID = 31,
    XR_FACE_PARAMETER_INDICES_LIP_CORNER_PULLER_L_ANDROID = 32,
    XR_FACE_PARAMETER_INDICES_LIP_CORNER_PULLER_R_ANDROID = 33,
    XR_FACE_PARAMETER_INDICES_LIP_FUNNELER_LB_ANDROID = 34,
    XR_FACE_PARAMETER_INDICES_LIP_FUNNELER_LT_ANDROID = 35,
    XR_FACE_PARAMETER_INDICES_LIP_FUNNELER_RB_ANDROID = 36,
    XR_FACE_PARAMETER_INDICES_LIP_FUNNELER_RT_ANDROID = 37,
    XR_FACE_PARAMETER_INDICES_LIP_PRESSOR_L_ANDROID = 38,
    XR_FACE_PARAMETER_INDICES_LIP_PRESSOR_R_ANDROID = 39,
    XR_FACE_PARAMETER_INDICES_LIP_PUCKER_L_ANDROID = 40,
    XR_FACE_PARAMETER_INDICES_LIP_PUCKER_R_ANDROID = 41,
    XR_FACE_PARAMETER_INDICES_LIP_STRETCHER_L_ANDROID = 42,
    XR_FACE_PARAMETER_INDICES_LIP_STRETCHER_R_ANDROID = 43,
    XR_FACE_PARAMETER_INDICES_LIP_SUCK_LB_ANDROID = 44,
    XR_FACE_PARAMETER_INDICES_LIP_SUCK_LT_ANDROID = 45,
    XR_FACE_PARAMETER_INDICES_LIP_SUCK_RB_ANDROID = 46,
    XR_FACE_PARAMETER_INDICES_LIP_SUCK_RT_ANDROID = 47,
    XR_FACE_PARAMETER_INDICES_LIP_TIGHTENER_L_ANDROID = 48,
    XR_FACE_PARAMETER_INDICES_LIP_TIGHTENER_R_ANDROID = 49,
    XR_FACE_PARAMETER_INDICES_LIPS_TOWARD_ANDROID = 50,
    XR_FACE_PARAMETER_INDICES_LOWER_LIP_DEPRESSOR_L_ANDROID = 51,
    XR_FACE_PARAMETER_INDICES_LOWER_LIP_DEPRESSOR_R_ANDROID = 52,
    XR_FACE_PARAMETER_INDICES_MOUTH_LEFT_ANDROID = 53,
    XR_FACE_PARAMETER_INDICES_MOUTH_RIGHT_ANDROID = 54,
    XR_FACE_PARAMETER_INDICES_NOSE_WRINKLER_L_ANDROID = 55,
    XR_FACE_PARAMETER_INDICES_NOSE_WRINKLER_R_ANDROID = 56,
    XR_FACE_PARAMETER_INDICES_OUTER_BROW_RAISER_L_ANDROID = 57,
    XR_FACE_PARAMETER_INDICES_OUTER_BROW_RAISER_R_ANDROID = 58,
    XR_FACE_PARAMETER_INDICES_UPPER_LID_RAISER_L_ANDROID = 59,
    XR_FACE_PARAMETER_INDICES_UPPER_LID_RAISER_R_ANDROID = 60,
    XR_FACE_PARAMETER_INDICES_UPPER_LIP_RAISER_L_ANDROID = 61,
    XR_FACE_PARAMETER_INDICES_UPPER_LIP_RAISER_R_ANDROID = 62,
    XR_FACE_PARAMETER_INDICES_TONGUE_OUT_ANDROID = 63,
    XR_FACE_PARAMETER_INDICES_TONGUE_LEFT_ANDROID = 64,
    XR_FACE_PARAMETER_INDICES_TONGUE_RIGHT_ANDROID = 65,
    XR_FACE_PARAMETER_INDICES_TONGUE_UP_ANDROID = 66,
    XR_FACE_PARAMETER_INDICES_TONGUE_DOWN_ANDROID = 67
} XrFaceParameterIndicesANDROID;

XrInstance instance; // previously initialized
XrSystemId systemId; // previously initialized
XrSession session; // previously initialized, e.g. created at app startup.

// The function pointers are previously initialized using xrGetInstanceProcAddr.
PFN_xrCreateFaceTrackerANDROID xrCreateFaceTrackerANDROID; // previously initialized
PFN_xrDestroyFaceTrackerANDROID xrDestroyFaceTrackerANDROID; // previously initialized
PFN_xrGetFaceStateANDROID xrGetFaceStateANDROID; // previously initialized
PFN_xrGetFaceCalibrationStateANDROID xrGetFaceCalibrationStateANDROID; // previously initialized

// Inspect system capability
XrSystemProperties properties{XR_TYPE_SYSTEM_PROPERTIES};
XrSystemFaceTrackingPropertiesANDROID faceTrackingProperties{XR_TYPE_SYSTEM_FACE_TRACKING_PROPERTIES_ANDROID};
properties.next = &faceTrackingProperties;
CHK_XR(xrGetSystemProperties(instance, systemId, &properties));
if (!faceTrackingProperties.supportsFaceTracking) {
  // face tracking is not supported.
  return;
}

XrFaceTrackerANDROID faceTracker;
XrFaceTrackerCreateInfoANDROID
        createInfo{.type = XR_TYPE_FACE_TRACKER_CREATE_INFO_ANDROID,
                    .next = nullptr};
CHK_XR(xrCreateFaceTrackerANDROID(session, &createInfo, &faceTracker));

// If the system supports face calibration:
XrBool32 isCalibrated;
CHK_XR(xrGetFaceCalibrationStateANDROID(faceTracker, &isCalibrated));
if (!isCalibrated) {
    // Redirect the user to system calibration setting.
}

XrFaceStateANDROID faceState;
float faceExpressionParameters[XR_FACE_PARAMETER_COUNT_ANDROID];
faceState.type = XR_TYPE_FACE_STATE_ANDROID;
faceState.next = nullptr;
faceState.parametersCapacityInput = XR_FACE_PARAMETER_COUNT_ANDROID;
faceState.parameters = faceExpressionParameters;
float regionConfidences[XR_FACE_REGION_CONFIDENCE_COUNT_ANDROID];
faceState.regionConfidencesCapacityInput = XR_FACE_REGION_CONFIDENCE_COUNT_ANDROID;
faceState.regionConfidences = regionConfidences;

while (1) {
    // ...
    // For every frame in the frame loop
    // ...
    XrFrameState frameState; // previously returned from xrWaitFrame

    XrFaceStateGetInfoANDROID faceGetInfo{
            .type = XR_TYPE_FACE_STATE_GET_INFO_ANDROID,
            .next = nullptr,
            .time = frameState.predictedDisplayTime,
    };

    CHK_XR(xrGetFaceStateANDROID(faceTracker, &faceGetInfo, &faceState));
    if (faceState.isValid) {
        for (uint32_t i = 0; i < XR_FACE_PARAMETER_COUNT_ANDROID; ++i) {
            // parameters[i] contains a weight of specific blend shape
        }
        for (uint32_t i = 0; i < XR_FACE_REGION_CONFIDENCE_COUNT_ANDROID; ++i) {
            // regionConfidences[i] contains a confidence value of a specific region
        }
    }
}

// after usage
CHK_XR(xrDestroyFaceTrackerANDROID(faceTracker));
